AEON Desktop Co2 Laser Engraver Machine for Wood Acrylic leather

Short Description:

working area: 5030 7045 9060

laser tube60W/80W/100W/RF30W/RF50W

  • Clean Pack technology
  •  High Speed Digital Step Motors
  •  Built-in Water Cooling System, Exhaust Fan and Air Assist Pump
  •  Standard Honeycomb Table
  •  Super fast engraving speeds of up to 1200mm/s
  •  Z-depth up to 150mm


Product Detail

Product Tags

AEON Desktop Co2 Laser Engraver Machine for Wood Acrylic leather-11

Technical Specifications of AEON Desktop Co2 Laser Engraver Machine for Wood Acrylic leather

  MIRA7 MIRA9
Working Area 700*450mm (17 3/4″ x 27 1/2″) 900*600mm(23 5/8″ x 35 1/2″)
Machine Size 1106mm*883mm*543mm (43 1/2″ x 34 3/4″ x 20 5/8″) 1306mm*1037mm*555mm(51 3/8″ x 40 3/4″ x 21 1/8″)
Machine Weight 392 lbs. (178kg) 502 lbs. (228kg)
Work Table Honeycomb + Blade Honeycomb + Blade
Cooling type Fan Cooled (3000) Water Chiller Vapor Compression (5000) Water Chiller
Laser tube type Co2 glass tube Co2 glass tube
Laser power 60W/80W/RF30W 60W/80W/100W/RF30W/RF50W
Z-Axis Travel 150mm(5 7/8”)
Air Assist 105W Built-In Air Pump
Blower 330W Built-In Exhaust Fan
Input Voltage 120V AC Single Phase
Rated Power 1200W
Engraving Speed 0-1200mm/second (0 - 47 ¹/₄" /second)
Cutting Speed 0-680mm/second (0 - 26 ⁴⁹/₆₄"/second)
Cutting Thickness 0-20mm (depends on different materials)
Max Acceleration Speed 5G
Laser Optical Control 0-100% Set by software
Minimum Engraving Size Minimum Font Size 1.0mm x 1.0mm(English Letter) 2.0mm*2.0mm(Chinese Character)
Max Scanning Precision 1000DPI
Locating Precision <=0.01mm
Red Dot Positioning Combiner Type
Built-in WIFI Included
Auto Focus Included
Engraving Software RD works/LightBurn
Graphic Format Supported AI/PDF/SC/DXF/HPGL/PLT/RD/SCPRO2/SVG/LBRN/BMP/JPG/JPEG/PNG/GIF/TIF/TIFF/TGA
Compatible Software CorelDraw/Photoshop/AutoCAD/All kinds of Embroidery Software
Add-Ons Roller Rotary, Rotary Chuck, Stand, Fume Extractor, Remote Control, Camera

Applications
